| SPECIFICATIONS |
| Transmitter Unit | Receiver Unit | |||||
Frequency Range | : | PLL 433 MHz | Frequency Range | : | 301, 433 MHz | |
| Transmitting Range | : | 100 Meters. / 300 Feet | Demodulation | : | Norrow Band FM | |
| Continuos Operation | : | 16+ Hours (600mA) | Frequency Control | : | Synthesizer (PLL) | |
| ID Code | : | 65,536 Sets. | Frequency Drift | : | < 5ppm @ -25°C~75°C | |
| Channel Spacing | : | 25 KHz. | Frequency Deviation | : | < 1ppm @ 25°C | |
| Hamming Distance | : | ≥ 6 | Sensitivity | : | -122dBm | |
| Channel Spacing | : | 25 KHz | Antenna lmpedance | : | 50ohms | |
| Frequency Control | : | Quartz Crtstals | Date Decoder Referenc | : | Quartz Crtstals | |
| Spurious Emission | : | - 50dB | Responding Time | : | 64~100 mS | |
| Transmitting Power | : | 1.0 mW | Enclosure Rating | : | IP-66 | |
| Antenna lmpedance | : | 50 ohms | Source Voltage | : | AC120V/220V/380V/415V | |
| Enclosure | : | IP-66 | @50/60 Hz. | |||
| Source Voltage | : | DC 6.0V | Power Consumption | : | 11VA | |
| Current Drain | : | ~ 8 mA @ 6V | Operating Temperature | : | -25°C ~ 75°C | |
| Operating Temperature | : | -25°C ~ 70°C | Output Contact Rating | : | 250V @10A | |
| Dimension | : | 230 x 78 x 47 mm. | Dimension | : | 425 x 245 x 130 mm. | |
| Weight | : | 600g (include batteries) | Weight | : | 8.0 Kg. | |
